Asustor

FS6812X

Asustor




Hardware Specifications
CPUCPU ModelAMD Ryzen V3C14
　CPU Architecturex64 64-bit
　CPU FrequencyQuad-Core 2.3GHz (burst up 3.80 GHz)
MemoryMemory16GB ECC DDR5-4800 SO-DIMM Compatibility
　Memory Module Pre-installed16GB (1x 16GB)
　Total Memory Slots2
　Memory Expandable up to64GB
Support mixed capacity
Supports ECC memory
ECC functionality will be disabled if non-ECC memory is installed or mixed with ECC memory
Installation Guide
　Flash Memory8GB eMMC
StorageM.2 Drive Slots12
　Compatible Drive Type CompatibilityM.2 2280 NVMe
　Maximum Drive Bays with Expansion Unit12
External PortsExpansion3 x USB 3.2 Gen 2 ( 10Gbps ) Type-A; 2 x USB 4.0 (40Gbps) Type-C
　Network2 x 10 Gigabit Ethernet (10G/2.5G/1G/100M)
　Multimedia OutputN/A
OthersSystem Fan1 x 80mm
　Power Supply Unit / Adapter120W x1
　Input Power Voltage100V to 240V AC
　CertificationFCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA
　Warranty3 Years
OperationPower Consumption32.2 W (Operation);
2.8 W (Sleep Mode)
　Noise Level18.6dB
　Operation Temperature0°C~40°C (32°F~104°F)
　Storage Temperature-20°C~70°C (-4°F~158°F)
　Humidity5% to 95% RH
Size and WeightSize48.3 (H) x 308.26 (W) x 193 (D) mm
　Weight1.45 kg / 3.19 lb

KC인증번호
(방송통신기자재등의 적합등록필증)		R-R-ASM-AS6706T
